S63 Micro 6-port DC/USB LiPo Smart Charger, 1S

This is the S63 Micro 6-port DC/USB 1S LiPo Smart Charger from Spektrum.

The Spektrum™ S63 DC/USB 1S LiPo Smart Charger is a portable 6-port device no RC pilot of ultra-micro aircraft should be without. Featuring Spektrum Smart™ Charger technology, the digital LED status screen keeps you in control of your ultra-micro 1S LiPo battery fleet by instantly displaying voltage no matter which of the six ports a battery is connected into.

Simply connect a 1S LiPo battery into one of the ports, and press Start—the Spektrum S63 LiPo Charger features integrated circuitry and six totally independent output charge ports dedicated to the 1S-type LiPo battery. For batteries with a 350mAh capacity or less, use ports 1-4; ports 5 and 6 have a higher charge rate for 1S batteries up to 750mAh.

Small size and low weight makes it easy to take anywhere

Six independent charge output ports can be used simultaneously

Operates from a wall outlet or standard USB port

Convenient voltage-check function

Digital LED displays Port and Voltage information

(6) Charging status lights (Red: Charging/Green: Full)

Charging current: 350mA (4), 500mA (2)

Works with a variety of 1S battery connector types

Ampere Meter: Yes - on main LCD display

Battery Type: 1S LiPo, LiPo (3.7V per cell)

Display: LED

Selectable Charge Rate: Yes - Incremental (0.1A Increments)

Voltage Meter: Yes - on main LCD display

Input Voltage: 5 VDC via USB charge port

Maximum Charge Rate: 500mAh

Output Connector: PH1.25

Programmable: No

Weight: 1.9 oz (54 g)

Height: 0.9 in (23 mm)

Length: 3.0 in (76 mm)

Width: 2.5 in (63 mm)

(1) Spektrum Charger

Brand: Spektrum

MPN: SPMXC1060
